Product positioning:

Smooth rides on city streets and long-distance commuting.

Target customer:

Middle-aged and older adults in suburban communities seeking cycling for exercise and leisure.

---

Selling points

1. Intelligent Control System: Comprehensive Upgrade for Riding Experience

Smart Automatic Gear System:

Supports automatic upshift/downshift, eliminating the need for frequent manual operation and making riding easier.

Dual Riding Modes:

Torque mode provides smooth power output, while cadence mode is ideal for high-speed cruising. Easily switch between modes to meet different riding needs.

5-inch High-Definition TFT Full-Color Display:

High-brightness display with 320×480 resolution, clearly visible even under strong outdoor sunlight.

Integrated Soft-Touch Buttons and Twist Throttle:

Convenient control with comfortable tactile feedback, throttle speed adjustment, and switchable dual power colors to personalize your riding experience.

Fully Customizable Settings:

Adjustable gear torque, pedal-assist ratio, power response, walking speed, multi-level throttle speed, and dual-theme color interface to meet personalized riding preferences.

Global OTA Updates:

Built-in WiFi module allows easy system upgrades anytime via hotspot, keeping your system up-to-date.

---

2. Power and Range: Strong, Efficient, and Reliable

Motor:

Ananda R520 750W rear hub motor, peak torque 70 N·m.

Controller:

Ananda, rated power 750W, peak power 900W (18A).

Torque Sensor:

Landson BBTS3PSD torque sensor (with bottom bracket), speed signal 36, torque 35mV/N·m.

Battery:

21700 Samsung/LG (UL1642) integrated down-tube battery.

Range:

Maximum assisted range 70 miles, typical assisted range 45 miles, maximum pure electric range 35.5 miles.

---

3. Safety and Braking: Ride with Confidence

High-Brightness Lighting System

Front Light:

120 LUX, safer night riding.

Tail Light:

Four safety warning modes for enhanced nighttime visibility.

Brakes:

SHIMANO MT200 180mm hydraulic disc brakes with instant motor cutoff, reliable even in rain or muddy conditions.

Front Fork Safety Design:

Safety barrel-axis fork, easy installation, no risk of front wheel detachment.

Waterproof Rating:

• Bike IPX5
• Battery IPX6
• Display IPX7

---

4. Suspension and Comfort: Stable and Comfortable Ride

Front Fork:

Long-travel suspension fork.

Rear Suspension:

Classic four-bar rear suspension.

Saddle:

220mm ultra-elastic scratch-resistant saddle with shock-absorbing balls, supports heavy riders and provides comfortable rebound.

Ergonomic Design:

0° rear-swept handlebars + 0–60° adjustable stem for upright and comfortable riding posture.

Quick-Release Adjustable Seatpost:

Fits riders of different heights.

Ergonomic Handlebar Grips with Palm Support:

Reduces wrist and elbow pressure.

Low Step-Through Design:

415mm frame height for easy mounting and dismounting.

Frame Functionality Expansion:

Four water bottle mount points on the down tube, supports water bottles, locks, speakers, and other accessories for convenient access.

---
